Controller
The heart of the cabinet. It runs the program, connects the technology and works without internet.
uni-PRO automation technology
Everything from one source
Controller, visualisation and app – one system, one project, one contact.
What is it about?
Four parts that work together perfectly
uni stands for universal – in the hardware as much as in the software. Hence the name.
Studio
One program for planning, logic and visualisation – all in a single project.
APP
Operation on phone, tablet and PC – at home and away, for Android, iOS and Windows.
VPN service
Secure remote access with no router settings, with servers in the EU.
The idea
All of a piece – like a well-planned house
Until now: the usual patchwork
A logic module here, a visualisation server there, a separate app, a router for remote access, plus gateways and a data logger. The result: several programs, several projects, addresses maintained more than once. When something goes wrong, everyone points at someone else.
With uni-PRO: one project
One project holds the logic, the visualisation and every address. The controller executes it, the app displays it. Nothing has to be maintained twice or kept in sync. If something changes, it is changed once – and is correct everywhere.
How it works
Three steps to a finished installation
1
Plan in the Studio
Import addresses from ETS, draw the logic, design the operating pages.
2
Test safely
First in memory only – once everything fits, store it permanently on the controller.
3
Operate
The app shows exactly what was designed in the Studio – at home and away.
DIN-rail controller: up to 4,000 addresses · server PC: up to 16,000 addresses. No limit on operating pages, images and controls.
The advantages
Twelve reasons for uni-PRO
1
Control and visualisation in one
Logic and operating pages are created in the same program and access the same addresses. A switch in the app and a block in the logic automatically share the same value. Pages, images and controls are freely designable – no forced templates, no quantity limits.
2
Open to (almost) everything
KNX is built in. On top of that: Modbus, M-Bus, DMX, CAN, MQTT and Matter, plus many devices without an extra gateway – Shelly, wallboxes, inverters, batteries, cameras, door stations, Hue, Sonos and more. You choose the technology the building needs, not what the controller happens to understand.
3
The ecosystem: app and VPN
The app is available for Android, iPhone/iPad and Windows. Remote access runs through the uni-PRO VPN service – no port forwarding on the router, servers located in the EU. The installation stays local: if the internet fails, everything keeps running. Push messages arrive directly in the app and the installer shares access with a single link.
4
Remote service without a site visit
Through the same secure connection the installer works on the system with the Studio – and even programs KNX devices with ETS remotely. The controller includes its own KNX IP gateway. Other devices on site are reached through a tunnel, for example their web interface.
5
Heating, climate and ventilation built in
Heating circuits with heating curve, heat generators, hot water, circulation, mixers, solar, individual room control, air conditioners and ventilation – as ready-made blocks, without additional controllers. A single heating-circuit block replaces six to ten individual blocks.
6
Functions that learn
The room controller learns how long each room needs to heat up and starts early enough, so the room is warm at the set time. The PV forecast continuously compares itself with the actual yield, and irrigation learns the consumption of each zone.
7
Using energy intelligently
PV surplus is distributed by priority: heat pump, wallbox, heating element. The battery is managed according to electricity price and solar forecast. Wallboxes connect directly or via OCPP, dynamic tariffs are built in. The app shows consumption, generation and self-sufficiency at a glance.
8
Comfort as standard
Light, shading, scenes, time switches with holidays and solar times, alarm messages, gates and irrigation – as ready-made controls with matching logic. Every element knows Present, Absent and Holiday. Presence simulation is included.
9
Everything visible, nothing guessed
Diagnostics show the traffic of every bus system – KNX, Modbus, MQTT and more – in one place. The telegram monitor can record over days. Statistics store measured values directly in the controller: temperatures, meter readings, power – as charts in the Studio and in the app.
10
Engineered quickly
Addresses come straight from ETS. One drag links an element completely – all addresses of a blind at once. The project generator builds rooms, logic, operating pages and navigation from the ETS addresses. And if you like, an AI assistant helps.
11
Extensible and fail-safe
If the ready-made blocks are not enough, you write your own sequences as a Lua script – up to querying web services. Node-RED, Home Assistant and your own programs connect through open interfaces. Large systems spread across up to 16 controllers in one project. A backup controller takes over automatically.
12
Tailor-made – “uni” means universal
On request we build custom controls and function blocks that only your company sees, or a script block for one specific project. uni-PRO also runs on customer hardware – from building automation to machine control. Large partners receive their own branding, up to their own app in the App Store.
In comparison
Conventional solution or uni-PRO?
| Conventional solution | uni-PRO | |
|---|---|---|
| Architecture | several devices and programs | controller, visualisation and app from one source |
| Project | maintain addresses several times | one project, change once |
| Remote access | port forwarding or extra device | VPN service, EU servers, no port forwarding |
| KNX remote programming | separate gateway and tunnel | IP gateway inside the controller |
| Visualisation | fixed templates | freely designable, no quantity limits |
| Heating and energy | extra controllers and devices | HVAC and energy management built in |
| Troubleshooting | a separate tool per bus | diagnostics for all bus systems in one place |
| Openness | own devices only | KNX, Modbus, MQTT, Matter, script, API |
Typical applications
From the family home to the machine
Family home and villa
Light, shading, heating, PV and wallbox – operated in a single app.
Housing and commercial
Several buildings, one project; meters and energy centrally in view.
Hotel, school, administration
Room control with schedules, fault messages by notification, fail-safe operation.
Industry and special solutions
Automation and machine control on our hardware or on yours.
Learn more
What would you like to know more about?
Every topic in detail – as a short presentation in the online help.
VisualisationVisu editor
LogicProgram editor
Addresseslinking
Fast engineeringGenerator, AI
Bus systemsand hardware
KNXin detail
DiagnosticsTelegram monitor
StatisticsRecording
APP & VPNEcosystem
Remote serviceETS over VPN
Heating, climateventilation
EnergyPV, storage, wallbox
ComfortLight, scenes
Third-party systemsDevices, services
ScriptLua
Custom solutionsuniversal
Distributed projectup to 16 controllers
Backupcontroller
Let's talk about your project
Would you like to ask a question or discuss working together? We reply quickly and without red tape.
